Shoreline Cottage House Plan

https://houseplans.southernliving.com/web/image/product.template/11045/image_1920?unique=b6b2f20

Details: 930 Sq Ft, 3 Bedrooms, 1 Baths

$ 1,365.00 1365.0 USD $ 1,365.00

$ 0.00

Not Available For Sale

  • Plan Package
  • Foundation
  • Additional Sets
  • Additional Options

This combination does not exist.

Contact Us
Foundation: Crawlspace

Floor Plan Features of the Shoreline Cottage House Plan

Specifications

Floors: 2
Bedrooms: 3
Bathrooms: 1.0
Foundation(s): Crawlspace

Square Feet

Main Floor: 580
Upper Floor: 350
Total Conditioned: 930

Dimensions

Width: 20'-0"
Depth: 28'-0"
Height: 22'-0"

House Levels

Level Name Ceiling Heights
Main Floor 8'-0"
Upper Floor 8'-0"

Construction

Wall Construction: 2x6
Exterior Finish: Lap Siding, Board & Batten
Roof Pitch: 10:12

Features

Kitchen: Galley
Additional: Fireplace, Loft

Garage

Type Size
None

Description

Inspiration for the Shoreline Cottage came from the desire for a simple house that would capture serene views from all sides. An urban family in northwest Washington, challenged the architect to create the ideal weekend getaway for their site. The criteria for this retreat included that it be small, livable, and easy to maintain. The board-and-batten exterior, gabled roof, and generous porch set a traditional tone, while tall windows and an open interior make the home more modern. The result is an inviting version of old farm cabins and country cottages.

The main level offers an open space that combines the living room, kitchen, and dining room. An island visually separates the kitchen and dining area. Other thoughtful design elements include built-in window seats on two walls in the open living space - ideal for storage and comfortable reading spots. Two bedrooms and a bath complete the main level; upstairs, a sleeping loft (accessed by ladder) provides additional accommodations or storage.

Designed by Prentiss Architects, Inc.

CAD File
Source drawing files of the plan. This package is best provided to a local design professional when customizing the plan with architect.

PDF Plan Set
Downloadable file of the complete drawing set. Required for customization or printing large number of sets for sub-contractors.

Construction Set
Five complete sets of construction plans, when building the house as-is or with minor field adjustments. This set is stamped with a copyright.

Pricing Set
Recommended for construction bids or pricing. Stamped "Not For Construction". The purchase price can be applied toward an upgrade to other packages of the same plan.
