Bedrooms:
3
actual,
3
possible
Baths:
3
full,
1
half
Floors:
2
Garage:
1
Foundations:
Pole/Pier
Master Location:
Main Floor
Laundry Location:
Upper Floor
Fireplaces:
0
West Bay Landing
Plan SL-076
Details
|
Basics
Style / Influences
Country Southern Beach/Coastal
Kitchen Features
Snack
Master Suite Features
Dual Sinks Shower Tub Outdoor Access
Additional Features
Porch
Patio/Terrace
Summer Kitchen
|
Square Footage
Main Floor:
1197
Upper Floor:
854
Lower Level:
0
Total Heated Square Footage:
2051
Garage:
0
Dimensions
32 '- 0 " W x 99 '- 0 " D x 34 "- 0 " H
Plate Heights
Main Floor:
10.0
'
Upper Floor:
12.0
'
Construction
Ext. Wall Construction:
Roof Framing:
Gable
|
Description
To view a virtual tour for this plan, please click here.
Plan Packages
Reproducible + 1 set
Best for construction / customization. (Includes one free blueprint)
Mirrored (reverse print) sets
(Floor plans are reversed from plan as shown.
All text and dimensions read backwards.)
Construction Set - 8 Sets
Eight full sets of construction drawings.
per additional set.
Mirrored (reverse print) sets
(Floor plans are reversed from plan as shown.
All text and dimensions read backwards.)
Planning Set
Recommended for review/study only. Stamped "Not For Construction". Includes all exterior elevations and floor plans. Purchase price will be applied to any upgrade order for the same plan, based on availability (8 sets, CAD or Reproducible)
per additional set.
Mirrored (reverse print) sets
(Floor plans are reversed from plan as shown.
All text and dimensions read backwards.)
Study Plan (Downloadable)
Letter size document with floor plans and exterior elevations and color photography (if available)
